EVH SA-126 Special, Stealth Black

The all-new SA-126 features a Mahogany body that is chambered, with a basswood Centerblock added for stability and tone. Capped with a maple top on solid finishes and quilt maple on transparent finishes w/ 5 ply body binding, this thing emits “TONE”. The neck is a 22 fret 12”-16” compound Ebony fingerboard with jumbo frets and triple block inlays on a graphite reinforced mahogany neck. With a scale length of 24 and three quarters… this feels like a modern - classic that is familiar and comfortable. Finally, a spoke wheel truss rod adjustment at the butt end of the neck for easy adjustments, on the fly.

Introducing the EVH SA-126 bridge and neck pickups created by Fender’s resident pickup designer Tim Shaw and the EVH team, they can handle just about anything you feed them. From the elegant sound of cascading-glassy cleans to a heavy bath of Overdrive to “Burn” that will satisfy the most discerning gainiac. Three-way toggle at the upper horn to switch between bridge, bridge and neck, and neck pickups as well as two volumes and two tones to control each. Other features include a Harmonica bridge and stop bar tailpiece, oversized strap buttons, and keystone tuning pegs.

Neck
Headstock Binding: 1-Ply Cream
Neck Material: 2-Piece Mahogany
Neck Finish: Natural Satin
Neck Shape: EVH® Modified "C" Backshape
Fingerboard Radius: 12"-16" Compound Radius (304.8 mm to 406.4 mm)
Fingerboard Material: Ebony
Position Inlays: Triple Block
Side Dots: White
Number of Frets: 22
Truss Rod: EVH®-Branded with Wheel
String Nut: Graph Tech® TUSQ®
Nut Width: 1.75" (44.45 mm)
Nut Material: Graph Tech® TUSQ®

Body
Body: Chambered mahogany body with a basswood centerblock
Body Finish: Satin Urethane
Body Shape: SA-126
Body Binding: 5-Ply
Body Material: Chambered mahogany body with a basswood centerblock

Hardware
Bridge: EVH® Harmonica
Bridge Mounting: Secured
Control Knobs: Skirted Black Plastic with Numbered Indicators
Switch Tip: Black
Hardware Finish: Black
Tuning Machines: EVH® Keystone Tuners
Strings: Nickel Plated Steel (.009-.046 Gauges)
Strap Buttons: Oversized

Electronics
Bridge Pickup: EVH® SA-126 Humbucking
Neck Pickup: EVH® SA-126 Humbucking
Pickup Configuration: HH
Controls: Volume 1. (Neck Pickup), Tone 1. (Neck Pickup), Volume 2. (Bridge Pickup), Tone 2. (Bridge Pickup)
Switching: 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge And Neck Pickups, Position 3. Neck Pickup
