S-TECH WOOD Roasted Maple fretboard w/Black dot inlay
S-TECH special roasted treatment provides a superior attack and a well-balanced tone and a rich sustain. In order to achieve supreme neck grip comfort, the fretboard edge is finished with a smooth curve.
dyna-MIX 9 switching system w/Alter switch
dyna-MIX 9 offers nine sound variations, and can easily switch between humbucker and single coil modes with just the mini switch. One mode is even able to simulate a humbucker sound from the combination of the 2 single coil pickups
Oil-impregnated Bone nut /Stainless Steel Frets
The Oil-impregnated bone nut provides superior tuning stability and warm rich resonance. Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response, good articulation when playing chords and clear tone when playing single notes.
Seymour Duncan® Hyperion™ Pickups
Seymour Duncan® Hyperion™ Pickups feature a moderate output through Alnico-5 magnets to keep the clarity of the fundamental tone when using a distortion sound, and to deliver a clear pick attack. From treble to bass, the overall tonal balance is evenly adjusted., and works well with various effect pedals.
Gotoh® Magnum Lock machine heads w/H.A.P.(Height Adjustable Post)
The AZ comes with GOTOH® MAGNUM LOCK® machine heads, which have an established reputation for tuning stability. Its H. A. P® (Height Adjustable Post). system allows for the adjustment of string posts for the appropriate tension of each string.
neck type: AZ Oval CS-TECH WOOD Roasted Maple neck
top/back/body: Alder body
fretboard: S-TECH WOOD Roasted Maple fretboardBlack dot inlay
fret: Jumbo Stainless Steel fretsPrestige fret edge treatment
number of frets: 22
bridge: Gotoh® T1802 tremolo bridge
string space: 10.5mm
neck pickup: Seymour Duncan® Hyperion™ (S) neck pickupPassive/Alnico
middle pickup: Seymour Duncan® Hyperion™ (S) middle pickupPassive/Alnico
bridge pickup: Seymour Duncan® Hyperion™ (H) bridge pickupPassive/Alnico
factory tuning: 1E,2B,3G,4D,5A,6E
strings: D'Addario® EXL110
string gauge: .010/.013/.017/.026/.036/.046
nut: Bone nut
hardware color: Chrome
